VT IEPE-2G05: PC USB IEPE/ICP Data Acquisition Interface 48kSPS 0.03~23kHz 24Bit

VT IEPE-2G05 is a 24-bit, dual-channel, USB data acquisition interface specially designed for use with IEPE sensors such as IEPE accelerometers, IEPE microphones and IEPE hydrophones. Each channel has six calibrated voltage measurement ranges for easy calibration to sensor sensitivity: ± 250 mV, ± 500 mV, ± 1 V, ± 2.5 V, ± 5 V, ± 10 V, and a built-in 24V 4mA current source to drive an IEPE sensor directly. It contains a hardware high pass filter with 5 selectable -3dB corner frequencies: None (0.03Hz), 1.8 Hz, 119 Hz, 236 Hz and 464 Hz. The signals sensed by the IEPE sensors can be amplified and output directly from the stereo headphone jack even without running the PC software. When used in conjunction with the Multi-Instrument software, the setup allows you to take reliable and quality vibration and noise measurements as simply as plug & play. No external power supply and driver installation is required. It is a truly hassle-free portable vibration and noise test & measurement solution. Package Contents: (1) VT IEPE-2G05 unit with a hardware activated Multi-Instrument Standard software license; (2) USB cable (1.5 m); (3) CD (contains the copy-protected Multi-Instrument Software) ; (4) Carrying case Note: No IEPE sensors, sensor cables and magnetic mounting bases are included. But it is possible to put them in the carrying case.

• 24-bit dual-channel data acquisition IEPE / ICP interface
• 48 kHz sampling rate, 0.03Hz~23kHz bandwidth, 6 voltage ranges
• Built-in 24V 4mA constant current supply to IEPE sensors
• USB bus powered, no external power supply needed, Plug & Play
• Support direct monitoring IEPE signals through earphones
